Kingston Fury Beast Black RGB Expo 32GB 6000MT/s DDR5 CL30 Gaming Memory Kit of 2 - KF560C30BBEAK2-32

The KF560C30BBEAK2-32 is a high-performance 32GB Dual-Channel Kit (comprising two 16GB modules) from the Kingston FURY Beast DDR5 RGB series.

This specific model is highly sought after because it hits the "Performance Sweet Spot" for modern gaming—combining a high 6000MT/s clock speed with an ultra-low CL30 latency.

General Specifications

Core Kit Identity

• Model Number: KF560C30BBEAK2-32

• Kit Capacity: 32GB (2 x 16GB Modules)

• Memory Type: DDR5

• Form Factor: 288-pin UDIMM (Desktop)

• Speed: 6000 MT/s (PC5-48000)

Timing & Performance

• CAS Latency: CL30

• Tested Timings: 30-36-36

• Tested Voltage: 1.4V

• Default (JEDEC): 4800 MT/s at 1.1V

• Overclocking Profiles: Intel XMP 3.0 & AMD EXPO (Dual Certified)

Aesthetics & Physical Build

Lighting & Control

• LED Type: Addressable RGB (Customizable via FURY CTRL or Motherboard software)

• Sync Technology: Kingston FURY Infrared Sync Technology™ (Keeps patterns aligned across both sticks)

Dimensions

• Heat Spreader: Black Aluminum

• Height: 41.24 mm

• Width: 133.35 mm

• Thickness: 7 mm

Technical Features

The CL30 Advantage This kit is optimized for ultra-low latency. While standard DDR5 modules often run at CL36 or CL40, the CL30 rating provides faster data access, which significantly improves 0.1% and 1% low FPS in gaming, resulting in a much smoother experience.

Enhanced Power Management Because this kit pushes high performance at 1.4V, it utilizes an on-board PMIC (Power Management Integrated Circuit) to ensure that the voltage remains stable even during extreme gaming sessions or heavy rendering workloads.

On-Die ECC Includes built-in Error Correction Code at the chip level to manage data integrity, which is critical when running at high frequencies like 6000MT/s.

Compatibility Note

• CPU Synergy: This kit is exceptionally well-matched for AMD Ryzen 7000/8000/9000 series (AM5) and Intel 13th/14th/15th Gen processors.

• Motherboard: Requires a DDR5-compatible motherboard.

• Cooler Clearance: At 41.24mm tall, ensure your CPU air cooler provides enough clearance, as some large "dual-tower" coolers may sit very close to the RAM slots.

Warranty

• Description: Limited Lifetime Warranty.
